Switches Operating Mechanism: Mechanism at the End of the Switch 03 (Left Side).Power Loss: at Rated Operating Conditions per Pole 6.5 W.Rated Conditional Short-Circuit Current (I nc): (200 A fuse, 500 V) 100 kA (200 A fuse, 690 V) 50 kA.Rated Short-time Withstand Current Low Voltage (I cw): for 1 s 4 kA.Rated Short-Circuit Making Capacity (I cm): (690 V) 12 kA.Rated Operational Voltage: Main Circuit 1000 V.Rated Impulse Withstand Voltage (U imp): 12 kV.Conventional Thermal Current (I the): Fully Enclosed 160 A.Conventional Free-air Thermal Current (I th): Θ = 40 ☌ 160 A.
Rated Operational Power AC-23A (P e): (220.Rated Operational Current AC-23A (I e): (380.Rated Operational Current AC-22A (I e): (380.Rated Operational Current AC-21A (I e): (380.Environmental Information: 1SCC301267D0201.
